10mm Hole Aluminium Perforated Sheet (R10 U26)

Need help in choosing the right product?

Ask our experts

CONTACT US

10mm Hole Aluminium Perforated Sheet (R10 U26)

Perforated sheetAluminiumKenton code K465A

10mmRound hole
26mmSquare pitch
12%Open area
1–4mmThickness

Stock and sheet sizes

AluminiumK465A 2000 x 1000 2500 x 1250 3000 x 1500 kg/m²
1.0mm 5-7 days 5-7 days 5-7 days 2.4
1.5mm 5-7 days 5-7 days 5-7 days 3.6
2.0mm 5-7 days 5-7 days 5-7 days 4.8
3.0mm 5-7 days 5-7 days 5-7 days 7.2
4.0mm 5-7 days 9.6

✓ In stockon the shelf, ready to send5-7 daysmade to orderBlank = not a standard size · sizes in mm

  • Cut to sizewhile you wait
  • Next working daydelivery on stock sheets
  • Folded & fabricatedto your drawing
Need a price?Tell us the thickness, sizes and quantity and we’ll come back to you.

0117 963 4579Email us

Description

Technical details

Hole layout

R10 U26 hole layout: 10mm round holes, 26mm square pitch, 16mm bar

Enlarged, not to scale. Dimensions in mm, pitch measured centre to centre.

Specification

Hole
10mm round
Pitch
26mm square
Bar between holes
16mm
Open area
12%
Holes per m²
1,480
Thickness
1–4mm
Material
Aluminium
Need it cut, folded or made to a drawing?We guillotine sheets to size while you wait, and fold, roll and fabricate panels, guards and trays to your drawing.

Call 0117 963 4579Email your drawing

About R10 U26 aluminium perforated sheet

R10 U26 is a 10mm round hole perforated sheet in aluminium, with the holes on a 26mm square pitch giving 12% open area. It’s made to order, usually in 5-7 days, in thicknesses from 1 to 4mm.

All sizes in the table are made to order, usually in 5-7 days.

What does R10 U26 mean?

R10 is a 10mm round hole. U26 means the holes sit on a 26mm square (in-line) pitch, measured centre to centre.

This pattern also comes in

Mild steelPre-galvanised steelStainless 304Stainless 316

Similar patterns

Pattern Hole Pitch Open area Thickness Stock
R6 T9 6mm round 9mm staggered 40% 1–4mm ✓ In stock
R8 T12 8mm round 12mm staggered 40% 1–3mm ✓ In stock
R10 T15 10mm round 15mm staggered 40% 1–4mm ✓ In stock
R10 U21 10mm round 21mm square 18% 2mm 5-7 days
R10 U26This page 10mm round 26mm square 12% 1–4mm 5-7 days
R15 T21 15mm round 21mm staggered 46% 1–3mm 5-7 days
R20 U48.5 20mm round 48.5mm square 13% 1–3mm 5-7 days

The nearest aluminium round hole patterns to R10 U26. See every aluminium pattern →

Dimensions are nominal and weights approximate. Stock changes daily, so please call to confirm.
