8mm Hole Pre-Galvanised Steel Perforated Sheet (R8 T12)

Need help in choosing the right product?

Ask our experts

CONTACT US

8mm Hole Pre-Galvanised Steel Perforated Sheet (R8 T12)

Perforated sheetPre-galvanisedKenton code K060G

8mmRound hole
12mmStaggered pitch
40%Open area
1–3mmThickness

Stock and sheet sizes

Pre-galvanisedK060G 2000 x 1000 2500 x 1250 3000 x 1500 kg/m²
1.0mm 5-7 days 5-7 days 5-7 days 4.7
1.5mm 5-7 days 5-7 days 5-7 days 7.0
2.0mm 5-7 days 5-7 days 5-7 days 9.4
3.0mm 5-7 days 5-7 days 5-7 days 14.1

✓ In stockon the shelf, ready to send5-7 daysmade to orderBlank = not a standard size · sizes in mm

  • Cut to sizewhile you wait
  • Next working daydelivery on stock sheets
  • Folded & fabricatedto your drawing
Need a price?Tell us the thickness, sizes and quantity and we’ll come back to you.

0117 963 4579Email us

Description

Technical details

Hole layout

R8 T12 hole layout: 8mm round holes, 12mm staggered pitch, 4mm bar, 10.39mm row spacing

Enlarged, not to scale. Dimensions in mm, pitch measured centre to centre.

Specification

Hole
8mm round
Pitch
12mm staggered 60°
Row spacing
10.39mm
Bar between holes
4mm
Open area
40%
Holes per m²
8,020
Thickness
1–3mm
Material
Pre-galvanised
Need it cut, folded or made to a drawing?We guillotine sheets to size while you wait, and fold, roll and fabricate panels, guards and trays to your drawing.

Call 0117 963 4579Email your drawing

About R8 T12 pre-galvanised steel perforated sheet

R8 T12 is an 8mm round hole perforated sheet in pre-galvanised steel, with the holes on a 12mm staggered pitch giving 40% open area. It’s made to order, usually in 5-7 days, in thicknesses from 1 to 3mm.

All sizes in the table are made to order, usually in 5-7 days.

What does R8 T12 mean?

R8 is an 8mm round hole. T12 means the holes sit on a 12mm staggered (60°) pitch, measured centre to centre.

This pattern also comes in

Mild steelAluminiumStainless 304Stainless 316

Similar patterns

Pattern Hole Pitch Open area Thickness Stock
R6 T8 6mm round 8mm staggered 51% 1–1.5mm ✓ In stock
R8 T10 8mm round 10mm staggered 58% 0.75mm 5-7 days
R8 T11 8mm round 11mm staggered 48% 1–2mm 5-7 days
R8 T12This page 8mm round 12mm staggered 40% 1–3mm 5-7 days
R10 T14 10mm round 14mm staggered 46% 1–2mm 5-7 days
R10 T15 10mm round 15mm staggered 40% 1–3mm ✓ In stock
R10 U21 10mm round 21mm square 18% 2mm 5-7 days

The nearest pre-galvanised steel round hole patterns to R8 T12. See every pre-galvanised steel pattern →

Dimensions are nominal and weights approximate. Stock changes daily, so please call to confirm.
